3300 GTO

The New 3300 GTO is launched with the highest SAGOLA manufacturing standards, competitive prices whilst maintaining a superb service and offering the best warrantee (3 years). All this with strict compliance with the most demanding standards of manufacture and emissions of solvents, with EPA and HVLP systems.

Its new forged and anodized body and more ergonomic design together with the highest quality and efficiency nozzles, make a more attractive and versatile spray gun with an excellent value for money offering a wide range of solutions for different painting applications.

SAGOLA renews and improves the mid-high range of spray guns. The new 3300 GTO, is the result of the fusion of two of the most renown products: 3300 PRO (industry) and 4100 GTO (bodyshop).

VERSATILITY: WIDE RANGE OF SOLUTIONS

At the forefront of ergonomics, balance and comfort when painting.

Light but robust body, maintaining the construction in aluminium and stainless steel in all its pieces, giving it maximum robustness and minimum maintenance.

Easy and smooth use.

ANODIZED HIGH RESISTANCE with ANTI-CORROSIVE PROTECTION.

Easier for cleaning and maintenance process.

New Regulators design

Modern design. Without sharp edges. Better regulation precision. It avoids working loose unwittingly.

Paint packing gland

One single piece automatic Paint packing gland. It avoids manipulation and breakage of the glands and makes easier to remove it for a thorough cleaning.

Aircaps

Ultra-fine atomization and larger fans. Designed for the best response at any pressure.

Single axis system

Inherited directly from the Xtreme range, simplified design. Maximum reduction of components and maintenance.

Air Cap GTO EPA
	1.40	Primers
	1.60	Refinish Primers. Drying express
	1.80	HS Primers

Air Cap GTO 64S
	2.20	High-thickness Primers

Air Cap GTO 62S
	2.80	Spray gun Fillers

Air Cap GTO HVLP
	1.40	Primers
	1.60	Refinish Primers. Drying express
	1.80	HS Primers

Air Cap GTO EVO
	1.30	Wet/Wet Primers, Finishes
	1.40	Wet/Wet Primers, Industrial finishes
	1.60	High application speed, large surfaces

Weight without cup	474.8 g.
Dimensions without cup	18.2 x 1.9 x 17.8 cm.
Air inlet couplings	BSP 1/4” M
Cup capacity	650 ml
Cup	Removable anti-drip system
Maximum design pressure	8 bar
Air inlet pressure max	2 bar
Maximum recommended application distance GTO EPA	18 - 20 cm.
Maximum recommended application distance GTO HVLP	12 - 15 cm.
Average paint output flow (nozzle 1.4 mm. 20”) GTO EPA	179 g/min
Average paint output flow (nozzle 1.4 mm. 20”) GTO HVLP	145 g/min
Average paint output flow (nozzle 1.4 mm. 20”) GTO EVO	179 g/min
Air consumption (2 bar inlet) GTO EPA	250 L/min
Air consumption (2 bar inlet) GTO HVLP	360 L/min
Air consumption (2 bar inlet) GTO EVO	255 L/min
Fan size GTO EPA [1.8]	250 mm.
Fan size GTO HVLP [1.8]	250 mm.
Fan size GTO EVO [1.4]	280 mm.
Average sound pressure level	80 dB

Code	Version
10141555	Gravity Spray Gun 3300 GTO 1.40[GTO HVLP
10141556	Gravity Spray Gun 3300 GTO 1.60[GTO HVLP
10141557	Gravity Spray Gun 3300 GTO 1.80[GTO HVLP
10141559	Gravity Spray Gun 3300 GTO 1.30 (EVO)
10141560	Gravity Spray Gun 3300 GTO 1.40 (EVO)
10141561	Gravity Spray Gun 3300 GTO 1.60 (EVO)
10141562	Gravity Spray Gun 3300 GTO 1.40(3300EPA)
10141563	Gravity Spray Gun 3300 GTO 1.60(3300EPA)
10141564	Gravity Spray Gun 3300 GTO 1.80(3300EPA)
10141572	Gravity Spray Gun 3300 GTO 2.20 (64S)
10141574	Gravity Spray Gun 3300 GTO 2.80 (62S)
10141575	Spray Gun 3300 GTO 1.40 (HVLP) Suitcase
10141576	Spray Gun 3300 GTO 1.60 (HVLP) Suitcase
10141577	Spray Gun 3300 GTO 1.80 (HVLP) Suitcase
10141578	Spray Gun 3300 GTO 1.40 (EPA) Suitcase
10141579	Spray Gun 3300 GTO 1.60 (EPA) Suitcase
10141580	Spray Gun 3300 GTO 1.8 (EPA) Suitcase
10141585	Spray Gun 3300 GTO 2.20 (64S) Suitcase
10141586	Spray Gun 3300 GTO 2.80 (62S) Suitcase
